C5EUSG_LSZH
CAT5e Cable UTP LSZH
Length:
Price: HK$0
download-icon Download Specification
Features
  • Conductor: 24 AWG, Solid-Bare Copper
  • Outer Jacket: LSZH (Complies RoHS)
  • Standard: ISO/IEC11801, TIA-568-C.2
  • ISO9001 Certified Manufacturing Plant
Specification

Standard

Standard

ISO/IEC11801, TIA-568-C.2

ISO9001 Certified Manufacturing Plant



General

Construction   U/UTP
Conductor Material Solid-Bare Copper
  Nom.O.D. 0.500 ± 0.005 mm
Insulation Material & Diameter  HDPE (0.88 ± 0.05 mm)
Sheath Thickness 0.50 ± 0.05 mm
  External O.D. 5.0 ± 0.4 mm
  Material  LSZH (Complies RoHS)
Rip-cord   Yes
Sheath Physical Properties (Before Aging) Tensile Strength  ≥ 10.0 Mpa
  Elongation ≥ 125 %
  Aging Period 100 °C x 24h x 7d
Sheath Physical Properties (After Aging) Tensile Strength  ≥ 8 Mpa
  Elongation ≥ 100 %
  Cold Bend -20 ± 2 °C x 4h, 8 x Cable O.D., No visible cracks
Electrical Characteristics (20°C) Impedance 1.0-100.0MHz: 100 Ω ±15 Ω
  Delay Skew 1.0-100.0MHz: ≤45 ns /100m
  DC Resistance Max. 9.38 Ω / 100m
  DC Conductor Resistance Unbalance Max. 5.0 %


Electric Performance

Frequency

(MHz)

Return Loss

(≥dB)

Attenuation(20°C)

(≤dB)

NEXT

(≥dB)

PHASE DELAY

(≤ns)

PSNEXT

(≥dB)

ELFEXT

(≥dB)

PSELFEXT

(≥dB)



1 20 2 65.3 570 62.3 63.8 60.8
4 23 4.1 56.3 552 53.3 51.8 48.8
8 24.5 5.8 51.8 546.73 48.8 45.7 42.7
10 25 6.5 50.3 545.38 47.3 43.8 40.8
16 25 8.2 47.2 543 44.4 39.7 36.7
20 25 9.3 45.8 542.05 42.8 37.8 34.8
25 24.3 10.4 44.3 541.2 41.3 35.8 32.8
31.25 23.6 11.7 42.9 540.44 39.9 33.9 30.9
62.5 21.5 17 38.4 538.55 35.4 27.9 24.9
100 20.1 22 35.3 537.6 32.3 23.8 20.8
