Features
- Compliant with HDCP 1.3
- Max. resolution up to 3840 x 2160@30Hz
- Each HDMI output can select same input or select standalone input
- Supports PCM, Dolby AC3, DTS5.1, DTS7.1 and DSD audio format
- Smart EDID management, makes it compatible with most display devices
Specification
Technical
| Port selection | Front panel buttons, Console commands, IR remote control |
| Smart EDID | Yes |
| Resolution | Up to 3840x2160@30Hz/ 1080P@60Hz 3D |
| HDMI version | 1.4 |
| HDCP version | 1.3 |
| Data rate | 10.2 Gbps |
| Input | 4xHDMI Type A , 24/26 AWG HDMI cable up to 10M (1080P@60Hz ) |
| Output | 4xHDMI Type A , 24/26 AWG HDMI cable up to 20M |
| ESD protection | Human body model - ±8KV (Air-gap discharge) |
General
| Dimensions (LxWxH) | 278 x 136 x 25mm |
| Weight | 1100 g |
| Power supply | DC 12V 2A |
| Operating temperature | 0 to 70°C |
| Storage temperature | -40 to 85°C |
| Operating Humidity | 10 to 90% RH |
