Features
- Available in Multimode fiber, from 2,4,6,8,12,16,24,48 & 96 cores
- Excellent mechanical and temperature performance
- Aramid yarn as strength member make cable have excellent tensile strength
- Excellent flexibility
- Easy to branch
- Cable complies with IEC60332-1-2:2015, IEC61034-2:2019, IEC60754-1:2019, IEC60793-2-10:2015, IEC62321:2008, IEC62321-5, ITU-TG652
Specification
General
| Fiber Type | 50 / 125 μm | |
| Attenuation (+20°C) |
@850nm @1300nm |
≦2.4 dB/km ≦0.6 dB/km |
| Bandwidth |
@850nm @1300nm |
≧3500 Mhz.km ≧500 Mhz.km |
| Numerical Aperture | 0.200 ± 0.015NA | |
| Non-Circularity of Core | ≦6% | |
| Core / Cladding Dimension | 50 /125 μm | |
| Buffering Diameter | 900 μm ± 50 μm | |
| Fiber Coating Diameter | 245 μm ± 7 μm | |
| Tensile StrenthLong / Short Term (N) | 300 / 800 N | |
| Crush Resistance Long / Short Term (N /100mm) | 300 / 1000 (N/100mm) | |
| Bending Radius Dynamics / Static (mm) | 20 / 10 D | |
| Coating Strip Force | ≦13.3 | |
| Operation Temperature | -20°C~60°C |
