Features
- Support DTMB digital TV signal measurement (GB20600-2006)
- Spectrum analyzer and analog TV measurement feature
- Echo analysis feature
- Long operating hours
- Built-in re-chargable Li-ion battery
- Support channel scan
- Tilt, C/N ratio measurementl
- Support FM signal and FM audio demodulation
Specification
DTMB Feature
| Frequency Range | 58 ~ 858 MHz |
| Frequency Resolution | 10 KHz |
| Range Power | 25 ~ 120 dBm |
| Level Resolution | 0.1dB |
| Level Accuracy | ± 1.5 dB |
| MER Range | 13 ~ 34 dB |
| BER | 1E-2 - 1E-8 |
| Echo Test | Yes |
| Other Features | Single, multi-carrier compatible, constellation diagram, MER, BER, modulation scheme, FEC code rate, frame Header mode, symbol interleaver |
Analog TV Feature
| Frequency Range | 5 ~1000 MHz |
| Frequency Resolution | 10 KHz |
| Level Range | 25dBμV ~ 120dBμV |
| Level Accuracy | ± 1.5dB |
| Other Test Functions | C /N, V/A, slope, limit, channel management, FM audio demodulation, channel scanning (EA1500 only) |
Spectrum Analyzer Feature
| Frequency Range | 5 - 1000 MHz |
| Level Range | 10dBμV - 120dBμV |
| Level Resolution | 0.1dB |
| Level Accuracy | ± 1.5dB |
| Measurement BW | 995MHz |
| SPAN Range | 8 MHz / 16MHz / 32MHz / 50 MHz / 100MHz / 200MHz / 500MHz / Full |
General
| Dimension | 279 x 118 x 57 mm |
| Weight | 740 g |
| Display Interface | Chinese |
| Battery | 8.4V/2.6AH Lithium |
| Battery Operating Hour | 5hr |
