Features
- Part numbers are permanently marked on the connector for easy identification
- Use 6262 aluminum alloy for excellent corrosion resistance
- Moisture-proof through durability design and implementation of UV Ozone-resistant EPDM O-rings
- Brass contact pin with bright acid tin plating providing excellent RF conductivity
- Cable center conductor cutting guide
- Visible entry of center conductor into siezing mechanism
- Same hexagon size used on both main body and back unit
- No torque wrench needed, metal to metal positive stop,ensures proper tightening of the connector
Specification
General
| Body Hex | Splice Model | |
| CommScope P3 or Times Fiber T10 | 1” | CTK-412SP-P3 |
| 1” | CTK-500SP-P3 | |
| CommScope QR | 1” | CTK-540SP-QR |
| Times Fiber TX10 | 1” | CTK-565SP-TX |
| Bandwidth | DC - 1 GHz | |
| Nominal Impedance | 75Ω | |
| Return Loss | ≥ 30 dB @ 1GHz | |
| Insertion Loss | < 0.1 dB @ 1GHz | |
| Operating Range | -40°C ~ 60°C | |
| Interface | Meet SCTE IPS SP 501 |
