Features
- 220V main power
- Push-pull technology
- Built-in adjustable attenuator & equalizer
- Built-in test point
- Connector F type
- Metal-plastic housing for indoor mounting
- Output test point and screw terminal for equipotential bonding
- Made in Europe
Specification
General
| Frequency Range (forward path) | 47 ~ 862 MHz |
| Gain | 34 dB |
| Frequency Response | ± 0.5 dB |
| Gain Adjustment | 20dB |
| Slope Adjustment, Typical | 18dB |
| Maximal Output Level IMD3 =60 dB (DIN45004B) | 117 dBμV |
| Output Level CTB, CSO (EN50083-3) | 101 dBμV |
| Input and Output Return Loss* | > 14 dB |
| Noise Figure | < 6 dB |
| Input / Output Interface | F, 75ohm |
| Test Point Attenuation | - 30 dB |
| Power Consumption | 230V ~ 50 / 60Hz / 3.5W |
| Operating Temperature Range | -20°C ~ 50°C |
| Dimensions/ Weight (packed) | 107 x 148 x 53 mm / 0.6 kg |
*When f ≧ 40MHz, return Loss ≧ 14dB (40MHz) -1.5dB / octave, but not less than10dB
