Features
- Return loss > 25dB at 1 GHz
- Aluminum body with chromate conversion
- Electrical impedance 75 ohms
- Use 6262 aluminum alloy for excellent corrosion resistance
- Moisture-proof through durability resign and implementation of UV Ozone-Resistant EPDM O-Rings
- Brass contact pins with bright acid tin plating providing excellent RF conductivity
Specification
General
| Bandwidth | DC to 1 GHz | |
| Nominal Impedance | 75 Ω | |
| Return Loss | > 25 dB @ 1GHz | |
| Insertion Loss | < 0.2 dB @ 1GHz | |
| Operating Range | -40°C ~ 60°C | |
| Interface | Meet SCTE IPS SP 501 / Meet SCTE IPS SP 400 |
