Features
- Supports audio output via optical or L/R AUX interfaces
- Supports 2.0/5.1/Auto modes of audio output
- Supports 8/10/12 bits colour depth
- Supports Dolby True HD, DTS-HD Master Audio, and
- Dolby Digital and AC-3 audio transmission
- Easy to switch input source with infrared remote control
Specification
Technical
| Port selection | Front panel buttons, Console commands, IR remote control |
| Smart EDID | --- |
| Resolution | 3840x2160@60Hz 4:4:4 |
| HDMI version | 2 |
| HDCP version | 2.2 |
| Data rate | 18 Gbps |
| Input | 4x HDMI Type A |
| Output | 1xHDMI Type A, 1xAUX(for L/R audio out), 1xS/PDIF audio out |
| ESD protection | Human body model - ±8KV (Air-gap discharge) |
General
| Chasing material | Aluminum alloy |
| Dimensions (LxWxH) | 196 x 80 x 24mm |
| Weight | 500g |
| Power supply | DC 5V 1A |
| Operating temperature | 0 to 70°C |
| Storage temperature | -40 to 85°C |
| Operating Humidity | 10 to 90% RH |
