Features
- 13A Wall socket X 2
- 13A independent On / Off Switches
- USB output with 23W for charging 2 USB device
- USB: Over-load, Over-heat and Short circuit protection
Specification
General
| 13A Wall Socket | 2 |
| Rate Voltage | 230V AC 50Hz |
| Rate Current | 13 Amps max. |
| Power Indicator | LED |
| USB | Output Total 23W |
| Type-C (PD)x1 | DC5V / 3A, DC9V / 2.25A, DC12V / 1.5A (Max.18W) |
| USB-A x1 | DC5V / 2.4A |
| Size | 85x145mm |
| International Safety Standard | Hong Kong: BS1363 |
| International: IEC 62368, EMC, IEC 62680 |
