Features
                    - High quality extrusion aluminum antennas
 - Click clack mechanism
 - Directors robustly attached to the central axle
 - Anti corrosion plastic
 - Shielded “F” connector (75Ω), ideal against impulsive noise

Specification
                    General
| Frequency Range | UHF (470-694MHz) |
| Channels | 21 - 48 |
| Directors | 35 |
| Beamwidth H/V | 29 / 34 |
| Front/Back Ratio | 32 |
| Polarization Adjustment | H - V |
| Windload (170Km/h) | 180N |
| Length (m) | 2.36 |
| Weight (Kg) | 3.8 |
