產品資訊
- Support VGA, HDMI full HD output simultaneously
- Support ONVIF; access third party
- Support web, CMS
- Support various mobile monitoring (iOS, Android)
- Support UTC
- Support AHD/TVI/CVI/CVBS/IP five signals
技術規格
Video
| Codec | H.265X | ||
| Monitor Quality | VGA,HDMI:HD | ||
| Preview Ability | 16 x 1080N | ||
| Encode Ability | 16 x 1080N@12fps | ||
| Decode Ability | 16 x 1080N@12fps | ||
| Multi-mode Input | Analog: 16 x 1080N | ||
| Hybrid: 16 x 1080N (Analog) + 4 x 1080P (Network) | |||
| Network: 16 x 1080N ; 4 x 5M | |||
| Motion Detection | Each screen can be set to 192 (16 x 12) detection areas; multi-level sensitivity can be set (Limited local channel) | ||
Audio
| Audio Compression | G.711A | ||
| Intercom | Support | ||
Record
| Record Mode | manual > alarm > motion detection > timing | ||
| Search Mode | Search by time, calendar, event, channel | ||
| Video Storage | HDD, network | ||
| Backup Mode | Network, USB hard disk, USB burner, SATA burner | ||
External Interface
| Video Input | 16ch BNC | ||
| Video Output | 1ch VGA, 1ch HDMI | ||
| Audio I/O | 2/1 | ||
| Alram I/O | 0/0 | ||
| Network Interface | RJ45 10M/100M self-adaption | ||
| Extension Interface | 2 x USB 2.0 ports | ||
General
| HDD | Max 8TB x2 | ||
| Power Supply | 12V | ||
| Working Environment | Temperature: 0°C-55°C | ||
| Humidity: 10%-90% | |||
| Atm:86kpa-106kpa | |||
