產品資訊
- 5ms響應時間
- HDMI、BNC、VGA 輸入、BNC 輸出
- 梳狀過濾器
- 音頻輸入
- 內置揚聲器
- 降噪
- 內置電源
技術規格
Panel
| Inch | 17” | |
| Resolution | 1280 x 1024 @60Hz | |
| Brightness | 300cd/m² | |
| Contrast | 1000:1 | |
| Viewing Angle Degree | 170°(H) / 160°(V) | |
| Pixel Pitch (mm) | 0.264 (H) x 0.264 (W) |
| Scan System | Interlace | |
| Comb Filter | Yes | |
| Screen Mode | 5:4 |
Input
| Composite | 1 (BNC) | |
| VGA | 1 | |
| HDMI | 1 | |
| Audio | 1 (3.5mm Stereo Plug) |
Output
| Composite | 1 (BNC) | |
| Audio | 1 (3.5mm Stereo Plug), Built-in 2W Stereo Speaker |
General
| Power Supply | AC100 - 240V | |
| Power Consumption | Less than 20W | |
| Dimension | A | 372 mm |
| B | 386 mm | |
| C | 318 mm | |
| D | 184 mm | |
| E | 61 mm | |
| Weight | 3.5 Kg | |
| VESA | 100 x 100 mm |
Dimension (Unit)
 |
