下載技術規格
產品資訊
- 低插入損耗
- 高可靠性
技術規格
General
| Operating Wavelength | 1260 ~ 1650 nm | |
| Insertion loss | Typical | 7.2 dB |
| Maximum | 7.4 dB | |
| Uniformity | Maximum | 0.8 dB |
| Polarization Dependent Loss | Maximum | 0.1 dB |
| Return loss | Maximum | ≥50 dB ( ≥55 dB with connector ) |
| Directivity | Maximum | ≥55 dB |
| Operating temperature | -20°C ~75°C | |
| Storage temperature | -40°C ~ 85°C |
下載文件
相關產品
