Features
  • Designed to seal without screws.
  • The compact size and flip-over cover bring easy operation as well as complete function
  • The splice trays are jointed with a hinge at one side, which makes the operation in each tray easier.
  • It is designed to prevent from operation damage.
Specification


General

For Number of Couplers Up to 24
Dimension   380 x 245 x 130 mm
Weight 5 kg
Max Capacity  48 Cores
Splice Tray Quantity  1~4
IP Grading IP68
Environmental Temperature  -40°C~ 65°C
