AC44(5G)
TV Antenna with 5G filter
Price: HK$0
download-icon Download Specification
Features
  • Frequency: 470-694 MHz
  • Channels: C21-48
  • Gain: 15.5dB
  • High quality extrusion aluminum antennas
  • Click clack mechanism
  • Directors robustly attached to the central axle
  • Anti corrosion plastic
  • Shielded “F” connector (75Ω), ideal against impulsive noise
Specification

General

Frequency Range 470-694MHz
Channels  21 - 48
Directors  25
Max Gain (dB)  15.5
Beamwidth H/V  35 / 42
Front/Back Ratio 28
Polarization Adjustment  H - V
Windload (170Km/h)  138N
Length (m)  1.29
Weight (Kg) 2.2
